J10-25YC/J10-20YD/J07YE 7.5-25 Ton Split System Condensing Units

16 IEER (YE) ; 13.2-15.2 IEER (YC) ; 13.4-15 IEER (YD)

J10-25YC/J10-20YD/J07YE 7.5-25 Ton
Split System Condensing Units

Contact us

J10-25YC/J10-20YD/J07YE split-system condenser units fit almost any outdoor location and weigh much less than similar, single-package units.

Features smart equipment controls
Condenser coils constructed from microchannel aluminum tubing
5-year limited compressor warranty and 1-year parts limited warranty

Reliable performance in a lightweight design

Johnson Controls J10-25YC/J10-20YD/J07YE Split-system Condenser Units deliver the reliable performance you need in a compact design suitable for any outdoor location. These split units are perfect for rooftops because they weigh much less than a single-package unit of similar capacity and are much easier to rig and support. With a durable build, condenser coils made with microchannel aluminum tubing, aluminum fins and vinyl-coated fan guards, these condenser units resist rust and deliver long-lasting, efficient operation.

A female employee at a dress store's billing counter handing a dress to a woman

Benefits

Easy installation

These compact units install easily on rooftops and at ground level thanks to a lightweight design and simplified piping connections.

Reliable performance

Built-in protections as well as five-minute, anti-short cycle timer and minimum compressor run time provide greater peace of mind.

Flexibility

Choose from two-pipe and four-pipe configurations for on-site flexibility and factory- or field-installed low ambient VFD control to 0˚F.

Features

Meets EPACT 2005 and exceeds ASHRAE 90.1-2019 efficiency standards
Includes filter drier ready for field installation and is Smart Equipment enabled
Inherently protected condenser fan motors
2-pipe and 4-pipe configurations
Five-minute, anti-short cycle timer and minimum compressor run time
Standard operation to 40°F; factory or field-installed low-ambient VFD control to 0°F
Factory-installed disconnects, convenience outlet and an E-coat coil option
Scroll compressors provide both high efficiency and reliability

Durable build with condenser coils constructed with microchannel aluminum tubing and aluminum fins
Crankcase heaters that will be de-energized when the compressor is operating
Self-contained, high and low pressure controls
Solid state or internal line break compressor motor protection
Class 2, 24-volt, thermostat control circuit
Copper stub-outs are factory-mounted on the suction and liquid lines to simplify field piping connections
Compressor staging for capacity reduction provides more economical operation and even temperature levels within the conditioned space

Resources

Technical guide

YC/YD/YE/PC/PD/PE/NC/ND/NL/
NM090 thru 300 R-410A Split System Units and Heat Pumps

View

Brochure

Commercial Split Systems Air conditioners and heat pumps 7.5-25 Tons

View
